13
DIP-1 DIP-2 DIP-3 DIP-4
Mode Transmission Band Prole SNR Margin
OFF CO G.INP Asymmetric 12dB
ON (default) CPE Interleave Symmetric 8dB
DIP-1: Mode (CO/CPE)
CO
(Central
Ofce)
The Master device mode, usually the CO
device, is located at the data center of ISP or
enterprise to link to the backbone.
CPE
(Customer
Premises
Equipment)
The Slave device mode, usually the CPE
device, is located at branch ofce, home or
remote side as the long reach data receiver.
The CPE can be connected to the PC, IP
camera or wireless access point or other
network devices.
Note
When the VDSL2 Bridge operates in CPE mode,
DIP switches 2, 3, and 4 are without function.
DIP-2: Transmission (G. INP and Interleave mode)
G. INP
Method of protection against bursts from other
devices or lines to impact your xDSL line.
Interleave
Method of error correction used on xDSL
line. Interleave requires additional latency to
improve resilience to burst of error.
