User Manual of WDAP-C3000AX, WDAP-3000AX, WDAP-W3000AX
- 53 -
4.1.3 Dashboard
The dashboard provides an overview of system information including connection, port, and system
status as shown in Figure 4-16.
Figure 4-16: Dashboard
Port Status
Object
Description
Ethernet port is in use.
Ethernet port is not in use.
Wireless Status
Object
Description
Wireless is in use.
Wireless is not in use.
System Information
Object
Description
CPU
Display the CPU loading
Memory
Display the memory usage
