User Manual of WDAP-C3000AX, WDAP-3000AX, WDAP-W3000AX
- 66 -
4.2.2 LAN
This page is used to configure the parameters for local area network which connects to the LAN port of
your router as shown in Figure 4-29. Here you may change the settings for IP address, subnet mask,
DHCP, etc.
Figure 4-29: LAN Setup
Object
Description
IP Address
The LAN IP address of the router and default is 192.168.1.1.
Net Mask
Default is 255.255.255.0.
4.2.3 UpnP
Figure 4-30: UpnP
Object
Description
UpnP
Set the function as enable or disable
