User Manual of WDAP-C3000AX, WDAP-3000AX, WDAP-W3000AX
- 97 -
4.5.7 Diagnostics
The page allows you to issue ICMP PING packets to troubleshoot IP connectivity issues. After you
press “Ping”, ICMP packets are transmitted, and the sequence number and roundtrip time are
displayed upon reception of a reply. The Page refreshes automatically until responses to all packets are
received, or until a timeout occurs. The ICMP Ping is shown in Figure 4-68.
Figure 4-68: Ping
Object
Description
Interface
Select an interface of the router.
Target Host
The destination IP Address or domain.
Number of Packets
Set the number of packets that will be transmitted; the
maximum is 100.
Ping
The time of ping.
