Quick Reference Manual
10
Fact ory Default Sett ings For the Planmeca Int ra (3.06)
Film
Adult kV mA Time Child kV mA Time
Bi t e wi ng 6 3 8 0 . 08 Bi t e wi ng 6 0 8 0 .0 6 4
End o 6 0 8 0 . 0 8 En do 6 0 8 0 . 0 6 4
Upper Occlusal 70 8 0.08 Upper Occulsal 66 8 0.064
Lower Occlusal 70 8 0.08 Lower Occulsal 66 8 0.064
Upper Centrals 60 8 0.08 Upper Centrals 60 8 0.05
Lower Cent rals 60 8 0.064 Lower Centrals 60 8 0.04
Upper Pre-molar 63 8 0.08 Upper Pre-molar 60 8 0.064
Lowe Pre-molar 63 8 0.064 Lowe Pre- mol ar 60 8 0.05
Upper Molars 63 8 0.1 Upper Molars 60 8 0.08
Lower M olars 63 8 0.08 Lower M olars 60 8 0.064
Digital
Adult kV mA Time Child kV mA Time
Bi t e wi ng 6 3 8 0 . 05 Bi t e wi ng 6 0 8 0 .0 4
End o 6 0 8 0 .0 5 En do 6 0 8 0 .0 4
Upper Occlusal 70 8 0.05 Upper Occlusal 66 8 0.04
Lower Occlusal 70 8 0.05 Lower Occlusal 66 8 0.04
Upper Centrals 60 8 0.05 Upper Centrals 60 8 0.032
Lower Cent rals 60 8 0.04 Lower Cent rals 60 8 0.02
Upper Pre-molar 63 8 0.05 Upper Pre-molar 60 8 0.04
Lowe Pre-molar 63 8 0.04 Lowe Pre-molar 60 8 0.032
Upper Molars 63 8 0.064 Upper Molars 60 8 0.05
Lower M olars 63 8 0.05 Lower M olars 60 8 0.04
Phosphorus
Adult kV mA Time Child kV mA Time
Bi t e wi ng 6 3 8 0 . 32 Bi t e wi ng 6 0 8 0 .2 5
End o 6 0 8 0 .3 2 En do 6 0 8 0 .2 5
Upper Occlusal 70 8 0.32 Upper Occlusal 66 8 0.25
Lower Occlusal 70 8 0.32 Lower Occlusal 66 8 0.25
Upper Centrals 60 8 0.32 Upper Centrals 60 8 0.2
Lower Cent rals 60 8 0.25 Lower Cent rals 60 8 0.16
Upper Pre-molar 63 8 0.32 Upper Pre-molar 60 8 0.25
Lowe Pre-molar 63 8 0.25 Lowe Pre-molar 60 8 0.2
Upper Molars 63 8 0.4 Upper Molars 60 8 0.32
Lower M olars 63 8 0.32 Lower M olars 60 8 0.25

Planmeca intra Specifications

General

Manufacturer	Planmeca
Model	Planmeca Intra
Frequency	50/60 Hz
Tube Voltage	60-70 kV
Tube Current	7 mA
Type	Dental X-ray Unit
Voltage	100-240 V
Weight	Varies depending on configuration; refer to specific model documentation
