Quick Reference Manual
19
Proline PCBs
665070
(3.51KP/2.07GP or earlier)
10002568
(Proline 5.x to 6.x)
665180
662051
471023
100105
17
Keyboard Processor
Keyboard Processor
Generat or Processor
Power Generat or
Low Volt age PCB
Tube head
CC/ EC Film
CC/ EC Digi t al
XEC/ XC
Generat or Processor
Keyboard Processor
Tube head
Proline
PSU PCB
10009419
10009814
10009812
10010517 = before XEC421512 w/ cables
10010327 = after XEC421512
10010470 &
10010471
