Planmeca intra Quick Reference Manual

Quick Reference Manual
18
CC/EC Beam Alignment
CC:
PAN
1. Hold CTL and CEPH key for 6 seconds.
2. Press CTL once let go, and then press the Co l l i m a t o r Sel ec t i o n key let go.
3. Press Exposure button to check beam.
4. If the beam is too left/right, use the mm +/- to move the beam. (Figure 4)
NOTE: The beam wil l not move whil e exposing. Adjust t he beam and t hen press t he exposure butt on t o check
alignment.
5. Press the Col l ima t or Sel ect i on key once to save changes.
NOTE: Pressi ng t he Cl ock key will al so advance t he collimator to next available beam position.
6. Press CTL then the Co l l i m a t o r Sel ec t i o n key to exit beam alignment mode.
7. Press the CEPH key to exit Service mode.
CEPH
1. Hold CEPH.
2. Follow the Pan instructions.
EC:
PAN
1. Hold CTL and Hidden key for 6 seconds to enter service mode.
2. Press CTL once let go, and then press the Cl o c k key let go to enter beam alignment
mode.
3. Press Exposure button to check beam
4. If the beam is too left/right, use the mm +/- to move the beam
NOTE: The beam wil l not move whil e exposing. Adjust t he beam and t hen press t he exposure butt on t o check
alignment.
5. Press the Cl o ck key once to save any changes.
NOTE: Pressi ng t he Cl ock key will al so advance t he collimator to next available beam position.
6. Press CTL then the Cl o ck key to exit beam alignment mode
7. Press the Hidden key to exit Service mode.
CEPH
1. Hold P, press exposure +/- to select Ceph collimator 4, 5, or 6. Let go of P.
2. Follow Pan instructions.

Planmeca intra Specifications

General

Manufacturer	Planmeca
Model	Planmeca Intra
Frequency	50/60 Hz
Tube Voltage	60-70 kV
Tube Current	7 mA
Type	Dental X-ray Unit
Voltage	100-240 V
Weight	Varies depending on configuration; refer to specific model documentation
