Planmeca intra Quick Reference Manual

Quick Reference Manual
4
vi. Help/Error Codes 133
vii. ProMax 2D Internal Wire Diagram 143
viii. ProMax 3D Internal Wire Diagram 144
C. Calibrating
i. ProMax Calibration Block Procedures 145
ii. ProMax DEC Calibration Procedures 148
iii. Abridged Digital Pan/Ceph Calibration Manual 153
IV. PROONE
A. Install
i. Wall Exposure Wire Diagram 194
ii. ProOne Dimensions 197
B. Troubleshooting
i. Updating Software 198
ii. Column Adjustment 199
iii. Help/Error Codes 203
iv. ProOne Internal Wire Diagram 208
C. Calibrating
i. Abridged Calibration Manual 209
V. PROSENSOR
i. Setting up an Ethernet ProSensor 241
ii. Quick Installation Guide for ProSensor Ethernet 247
iii. Quick Installation Guide for ProSensor USB 248
VI. SOFTWARE
A. Install
i. 2D Computer Specs 250
ii. Romexis User Login Setup 251
iii. Romexis DICOM Setup 257
iv. Romexis Configuration Setup 263
v. Romexis Template 18FMX & 4 BWX 267
vi. Integration Procedures for TWAIN 272
vii. Integration Procedures for Patterson Eaglesoft 274
viii. Mac Drivers Installation Procedures 276
B. Troubleshooting
i. SOLID Er11003 Troubleshooting 278
ii. Didapi Errors 279
iii. Troubleshooting ODBC Communication Error 280
iv. Digital ProMax Compatibility Chart 281
v. DxLoader (DxExport.exe): Export Dimaxis data to Romexis 282
C. Calibrating
i. Calibration Settings 286

Planmeca intra Specifications

General

Manufacturer	Planmeca
Model	Planmeca Intra
Frequency	50/60 Hz
Tube Voltage	60-70 kV
Tube Current	7 mA
Type	Dental X-ray Unit
Voltage	100-240 V
Weight	Varies depending on configuration; refer to specific model documentation
