Plockmatic SQF-200 SquareFolder User Manual

SQF-3-35
Replacement
Adjustment
29 November 2006
MECHANICS
Stop Gate Adjustment B
NOTE: This procedure must be performed if any mechanics in the stopgate have
been altered, or if the stop gate motor or stop gate has been replaced.
1. Tilt machine (
3.1.6).
2. Turn Stop Gate Cam using the Stop Gate Motor so that Stop Gate is in upper
position.
3. Measure between Lower Clamp [B] and Stop Gate [C] on one side only (which
side does not matter). Distance [D] should be 7.5 ± 0.2 mm.
4. Loosen Stop Gate Motor M2 mounting screws and move Stop Gate Motor to
obtain measurement (
x 4).
5. Perform Stop Gate Adjustment A.
