SQF-6-7
29 November 2006
Detailed De-
scription
PRINCIPLE OF OPERATION
6.3 PRINCIPLE OF OPERATION
Square folding sequence:
The stapled and folded booklet, and trimmed if selected, is transported up against
the Stop gate in the Squarefolder. The booklet is then compressed by the Set
Clamps, holding the booklet in place.
First the Stop gate moves downward and the Set Clamps compresses the Booklet.
The Roller motor moves (rolling) over the spine of the Booklet, pressing it up
against the Set clamps, producing the Square fold look.
When the Square folding sequence is completed, the Set Clamp moves up and
releases
its
griponthebooklet.ThebookletisnallytransportedoutontotheBelt
stacker.
