Specifications
BOARD TYPE (Model name) Standard (M-11S) Wide (M-11W)
Form Installation method Self-standing (T-shaped legs), or wall mounting
External dimensions
(T-shaped legs*¹)
W1470 × D700 × H1970 (Max) mm W1970 × D700 × H1970 (Max) mm
Main unit weight 26.0 kg (excluding printer) 30.0 kg (excluding printer)
T-shaped legs weight 9.6 kg
BOARD Panel Size H920 × W1300 mm H920 × W1800 mm
Effective reading size H900 × W1280 mm H900 × W1780 mm
Number of Pages 2
Paging Endless in one direction (Horizontal scrolling)
Drive method Sheet movement
Reading method CCD sensor reduction optical system
Reading illumination
light source
RGB LED
Reading resolution Main scanning direction (vertical sheet surface) 2.4 dots/mm (60 dpi or equivalent)
Sub scanning direction (horizontal sheet surface) 2.4 dots/mm (60 dpi or equivalent)
Reading time Black & white: approx. 15 s
Color: approx. 23 s
Black & white: approx. 20 s
Color: approx. 31 s
Memory Type USB Flash memory*²
Compatible FAT types FAT 12, 16, 32
File format PNG format*³ and associated HTML format
Interface USB1.1 or USB2.0 full-speed mode*
4
Control panel Control buttons ON/Standby, +, −, Print, Save, Reprint, Color, Density, Feed/Stop
LED Indicators Density, Color
Display 7-Segment (Page, Error#),
Added functions Clock Used for the timestamp and for file dating properties
(Includes backup battery for when there is a loss of power)
PC connection Transfer of sheet surface image data via USB (TWAIN supported)
Power supply AC power adapter Input : AC100–240V/50–60 Hz, Max 1.5 A
Output : DC 24 V, 2.71 A
Operating
conditions
Temperature: 10–35°C
Humidity: 30–85% (No condensation)
Recording
Section
Printer interface USB1.1 or USB2.0 full-speed mode*
4
compliant printers are supported
Miscellaneous Ruled lines 50 mm cross-ruled squares
Miscellaneous Special markers (black, red, blue, and green)
Remarks
*1: The height is adjustable at 1770, 1870 and 1970 mm.
*2: A USB memory is not included in the package.
*3: The PNG format can be opened with Internet Explorer 6.0 or above, or with a Web browser that supports PNG file access.
*4: Not correspond High-speed mode.
• Please note that for quality improvement purposes, specifications and design are subject to change without prior notice.
• Depending on the product name, the printer and T-shaped legs (stand) will be available separately.
