Appendix
* The printer is an option.
* Appearance of printer is for illustration purposes.
Connections between copyboard and printer
The installation method at the printer side will differ depending on your printer.
(1) Connect the copyboard’s printer connector with the printer’s USB connector using the supplied USB cable.
(2) Use the power cable supplied with the printer to connect the AC INPUT power connector of the printer with the (100 V AC)
wall outlet.
This completes the connection of the printer.
Now make the power connections of the copyboard. See “AC Power Adapter Connections” on Page E-13.
When connections are completed, fasten the cable with the supplied cable clips.
DC IN connector
Printer connector
USB cable
(supplied)
USB connector
AC INPUT
power connector
Power cable supplied
with the printer
AC power adapter
(supplied)
Wall outlet
To Next Page
