PMC PH-40 - Page 78

PART IDENTIFICATION
1
An asterisk (*) next to an item number represents a part that is different for specific models.
See the description in the part list table for details.
74
PH(X)-40 HEATER ASSEMBLY (PH-5/PH-7/PH-9 & PH-6/PH-8/PH-10)
ITEM
QTY
PART NUMBER
DESCRIPTION
FOR HEATER/
PROPORTIONER
1
1
GM-05423-1
HEATER BODY
ALL
2*
6
GM-05423-1250
FIRE ROD; 1250W, 3/4 NPT, 17.5"
PH-5
PH-6
6
GM-05423-1500
FIRE ROD; 1500W, 3/4 NPT, 17.5"
PH-7
PH-8
6
GM-05423-1750
FIRE ROD; 1750W, 3/4 NPT, 17.5”
PH-9
PH-10
3
6
GM-05423-7
SPRING 18"
ALL
4
6
HI-05034
12 ORB PLUG
ALL
5
3
HI-05033
3/4-16 O-RING PLUG
ALL
6
2
EL-05032
1/2 NPT LONG HEX NIPPLE
ALL
7
1
EL-00006A
OVERTEMP SWITCH
ALL
8
2
FLOOR STOCK
#6-32 X 3/8 BHCS
ALL
9
2
HI-05036
1/4 NPT FLUSH SEAL PIPE PLUG
ALL
10
1
HI-05021
THERMOCOUPLE; TYPE E
ALL
11
3
HI-05035
1/2 NPT FLUSH SEAL PIPE PLUG
ALL
12
2
GM-05423-9
PHENOLIC STANDOFF; BOTTOM FRONT
ALL
13
2
GM-05423-10
PHENOLIC STANDOFF; BOTTOM BACK
ALL
14
2
HI-05046-1/2
GAUGE MANIFOLD, 1/2
ALL
15*
1
EL-42-2200
PRESSURE SWITCH, 2200 PSI
PH-40
1
EL-42-3750
PRESSURE SWITCH, 3750 PSI
PHX-40
16
1
EL-00052
SOLENOID VALVE CONNECTOR
ALL
17
1
EL-00053
SOLENOID VALVE GASKET
ALL
18*
1
HI-05026
OUTLET HEATER FITTING “R”
PH-6
PH-8
PH-10
1
HI-05027
OUTLET HEATER FITTING “A”
PH-5
PH-7
PH-9
19
1
HI-05038
1/4 NPT X 9/16-18 JIC 90 DEG E
ALL
20
4
FLOOR STOCK
1/4-20 X 3/4 BCHS
ALL
21
4
FLOOR STOCK
1/4-20 X 7/8 BHCS
ALL
22
1
200219
1/2 NPTF MALE X 1/2 NPTF FEMALE
ALL
