PART IDENTIFICATION
1
An asterisk (*) next to an item number represents a part that is different for specific models.
See the description in the part list table for details.
75
PH(X)-40 HEATER ASSEMBLY
ITEM
QTY
PART NUMBER
DESCRIPTION
1
1
PH-5
HEATER ASSEMBLY "A" SIDE; 7.5 KW
1
PH-7
HEATER ASSEMBLY "A" SIDE; 9 KW
1
PH-9
HEATER ASSEMBLY "A" SIDE; 10.5 KW
2
1
PH-6
HEATER ASSEMBLY "R" SIDE; 7.5 KW
1
PH-8
HEATER ASSEMBLY "R" SIDE; 9 KW
1
PH-10
HEATER ASSEMBLY "R" SIDE; 10.5 KW
NOTE: “A” AND “R” SIDE HEATERS ARE MIRRORED. THE ONLY DIFFERENCE IN
PARTS IS THE OULET FITTING (ITEM 19)
