PART IDENTIFICATION
1
An asterisk (*) next to an item number represents a part that is different for specific models.
See the description in the part list table for details.
85
PH SERIES PROPORTIONER (PH(X)-25 & PH(X)-40)
ITEM
QTY
PART
NUMBER
DESCRIPTION
FOR
MACHINE
1
1
FR-1
FRAME/TANK ASSEMBLY (PAGE 80)
ALL
2*
1
ML-1
MOTOR LINE ASSY; 3HP, 3PH, 50/60HZ (PAGE 82)
PH(X)-25
1
ML-2
MOTOR LINE ASSY; 3HP, 1PH, 60HZ (PAGE 82)
1
ML-3
MOTOR LINE ASSY; 5HP, 1PH, 60HZ (PAGE 82)
PH(X)-40
1
ML-4
MOTOR LINE ASSY; 5HP, 3PH, 50/60HZ (PAGE 82)
3*
1
PH-1
“A” SIDE HEATER; 5KW (PAGE 70)
PH(X)-25
1
PH-3
“A” SIDE HEATER; 6KW (PAGE 70)
1
PH-11
“A” SIDE HEATER; 4KW (PAGE 70)
1
PH-5
“A” SIDE HEATER; 7.5 KW (PAGE 73)
PH(X)-40
1
PH-7
“A” SIDE HEATER; 9.0 KW (PAGE 73)
1
PH-9
“A” SIDE HEATER; 10.5 KW (PAGE 73)
4*
1
PH-2
“R” SIDE HEATER; 5KW (PAGE 70)
PH(X)-25
1
PH-4
“R” SIDE HEATER; 6KW (PAGE 70)
1
PH-12
“R” SIDE HEATER; 4KW (PAGE 70)
1
PH-6
“R” SIDE HEATER; 7.5 KW (PAGE 73)
PH(X)-40
1
PH-8
“R” SIDE HEATER; 9.0 KW (PAGE 73)
1
PH-10
“R” SIDE HEATER; 10.5 KW (PAGE 73)
5
1
-
TRANSFORMER COVER ASSEMBLY (PAGE 77)
ALL
6*
1
EL-05225
90V TRANSFORMER
PH(X)-25
1
EL-05226
120V TRANSFORMER
PH(X)-40
7
1
CL-02001-05A
"A" HEATER COVER; BACK
ALL
8
1
CL-02001-06A
"A" HEATER COVER; FRONT
ALL
9
1
CL-02002-05A
"R" HEATER COVER; BACK
ALL
10
1
CL-02002-06A
"R" HEATER COVER; FRONT
ALL
11
2
CL-02001-07A
HEAT COVER; TOP
ALL
12
1
PL-1A
PUMPLINE ASSEMBLY; 120 PUMPS (PAGE 57)
ALL
1
PL-2
PUMPLINE ASSEMBLY; 80 PUMPS (PAGE 57)
ALL
13
2
EL-05220-01
CONSOLE KNOBS
ALL
14
1
MQ-01005A
REVERSING SWITCH; MOUNTING PLATE
ALL
15
20
FLOOR STOCK
1/4-20 X 3/4 HEX CAP SCREW
ALL
16
30
FLOOR STOCK
1/4 LOCK WASHER
ALL
17
30
FLOOR STOCK
1/4 PLAIN WASHER
ALL
18
2
EL-153
12MM PROX SWITCH
ALL
19
4
FLOOR STOCK
M10 X 1.5 HEX JAM NUT
ALL
20
2
FLOOR STOCK
1/4-20 X 1-1/4 HEX CAP SCREW
ALL
21
4
FLOOR STOCK
3/8-16 X 1 HEX CAP SCREW
ALL
22
4
FLOOR STOCK
3/8 LOCK WASHER
ALL
23
4
FLOOR STOCK
3/8 PLAIN WASHER
ALL
