PART IDENTIFICATION
1
An asterisk (*) next to an item number represents a part that is different for specific models.
See the description in the part list table for details.
86
PH SERIES PROPORTIONER (PH(X)-25 & PH(X)-40)
ITEM
QTY
PART
NUMBER
DESCRIPTION
FOR
MACHINE
24
4
FLOOR STOCK
5/16-18 X 1 HEX CAP SCREW
ALL
25
4
FLOOR STOCK
5/16 LOCK WASHER
ALL
26
8
FLOOR STOCK
1/4-20 X 1-1/2 HEX CAP SCREW
ALL
27
8
FLOOR STOCK
1/4-20 HEX NUT
ALL
28
32
FLOOR STOCK
#8-32 X 1/4 HEX BHCS
ALL
29
2
HI-05028
PRESSURE GAUGE 0-3000 PSI
PH-25
PH-40
2
HI-00035
PRESSURE GAUGE 0-5000 PSI
PHX-25
PHX-40
30
1
YS-1
Y-STRAINER ASSEMBLY "A" SIDE (PAGE 79)
ALL
31
1
YS-2
Y-STRAINER ASSEMBLY "R" SIDE (PAGE 79)
ALL
32
1
EL-00088-01A
HEYCO SR INCOMING POWER
ALL
33
1
EL-000P12
HAYCO #6
ALL
34
1
EL-000P13
STRAIN RELIEF
ALL
35
3
EL-05230-02
STRAIGHT CONDUIT CONNECTOR
ALL
36
1
EL-05230-03
RT ANGLE CONDUIT CONNNECTOR
ALL
37
1
MQ-01009-01A
LUBE BOTTLE (PAGE 87 FOR ALL COMPONENTS)
ALL
38
1
MQ-01009-02A
LUBE BOTTLE LID (PAGE 87 FOR ALL COMPONENTS)
ALL
39*
1
EL-502-33
CONSOLE ASSEMBLY; 3HP, 3PH
PH(X)-25
1
EL-501-31
CONSOLE ASSEMBLY; 3HP, 1PH
1
EL-504-53
CONSOLE ASSEMBLY; 5HP, 3PH
PH(X)-40
1
EL-503-51
CONSOLE ASSEMBLY; 5HP, 1PH
40
2
-
PRESSURE TRANSDUCER ASSEMBLY (PAGE 73)
ALL
