Point Grey Research Grasshopper Technical Reference
Introduction
Revised 26-Nov-10
Copyright (c) 2010 Point Grey Research Inc.
7
1.1.3. Camera and Device Control
Feature Description
Auto White Balance Auto and one-push white balance for easy color balancing
Frame Rate Control Fine-tune frame rates for video conversion (e.g. PAL @ 24 FPS)
Improved Strobe Output Increased drive strength, configurable strobe pattern output
RS-232 Serial Port Provides serial communication via GPIO TTL digital logic levels
Memory Channels Non-volatile storage of camera default power-up settings
Broadcast Properties Apply settings (e.g. shutter, gain) to all cameras on the same bus
Voltage Sensor Monitors sensor voltages to ensure optimal image quality
Camera Upgrades Firmware upgradeable in field via IEEE-1394 interface.
1.1.4. Mechanics and Form Factor
Feature Description
Compact Design 44mm x 29mm x 58mm, 104 grams
Industry Standard Mechanics ASA/ISO-compliant mounting bracket and C-mount lens holder
Jack Screw Connector 1394b cable jack screws provide secure connection
1.2. Using This Manual
This manual attempts to provide the user with a detailed specification of the Grasshopper camera
system. The reader should be aware that the camera system is a complex and dynamic system –
if any errors or omissions are found during experimentation, please contact us.
This document is subject to change without notice.
Many of the operational descriptions included in this manual are intended as general overviews,
and may not present the detailed information required for developing specific applications. For
additional details and operational descriptions, refer to the following resources that can be
downloaded from our website at
www.ptgrey.com/support/downloads/:
• Point Grey Digital Camera Register Reference
•
FlyCapture User Manual
• TAN2004004: Synchronizing to an external signal using DCAM 1.31 Trigger Mode_0
• TAN2004001: Configuring and testing the RS-232 serial port
• TAN2005002: Setting a GPIO pin to strobe using DCAM 1.31 Strobe Signal Output
• TAN2005003: Setting a GPIO pin to output a strobe signal pulse pattern
• TAN2005004: Buffering a GPIO pin output signal to drive an external device
• TAN2007004: A guide to transitioning from Scorpion
®
to Grasshopper
®
• TAN2007004: Accessing the On-Camera Frame Buffer
