Point Grey Grasshopper - Spectral Response

Point Grey Research Grasshopper Technical Reference
Introduction
Revised 26-Nov-10
Copyright (c) 2010 Point Grey Research Inc.
9
Operating
Temperature
Dimensions 44mm x 29mm x 58mm (excluding lens holder, without optics)
Mass 104 grams (without optics)
Lens Mount C-mount
Camera
Specification
IIDC 1394-based Digital Camera Specification v1.31
Voltage
Requirements
8-30V, via IEEE-1394b interface or 8-pin GPIO connector
Power
Requirements
(max)
3.9W 2.9W 3.0W 3.1W 3.4W 3.8W
Emissions
Compliance
Complies with CE rules and Part 15 Class A of FCC Rules
Operating
Temperature
0° to 40°C
Storage
Temperature
-30° to 60°C
Warranty Two years
Operating
Relative
Humidity
20 to 80% (no condensation)
Storage
Relative
Humidity
20 to 95% (no condensation)
* Measurements taken under the following conditions: Gain: 0 dB; Pixel Format: Format_7 Mode 0; Resolution: Max; Frame Rate: Max;
Shutter: 1 ms;
1.3.1. Spectral Response
L
All color models are equipped with an optical filter that prevents
infrared light from reaching the image sensor. This filter is discussed in
the section on Infrared Cut-Off Filters.
For spectral response curves, see
Appendix A: Spectral Response Curves.
