CLUTCH
6.2
DRIVE CLUTCH EXPLODED VIEW
EBS Drive Clutch
Mark with permanent
marker before disassembly
One way clutch
PVT SEALING AND DUCTING COMPONENTS
Clutch Cover
Clutch Inlet Duct
Clamps
Clutch Cover Seal
Seal Retainer
Bracket
Inner Cover
Seal
Transmission Cover
Seal
Inner Clutch
Cover
Boot Duct
Drain Plug
