ENGINE
3.10
600 ENGINE SERVICE DATA
Cylinder Head / Valve Engine No. -- EH059OLE
Camshaft Cam lobe height In
Std 1.3194” (33.5118 mm)
g
Ex
Std 1.3194” (33.5118 mm)
Camshaft journal OD
Mag 1.654” ± 0.00039” (42 ± 0.010 mm)
j
Center 1.634” ± 0.00039” (41.50 ± 0.010 mm)
PTO 1.614” ± 0.00039” (41 ± 0.010 mm)
Camshaft journal bore
I
D
Mag 1.656” ± 0.00039” (42.07 ± 0.010 mm)
j
ID
Center 1.637” ± 0.00039” (41.58 ± 0.010 mm)
PTO 1.617” ± 0.00039” (41.07 ± 0.010 mm)
Camshaft Oil clear-
Std 0.00118” ± 0.00079” (0.03 ± 0.02 mm)
ance
End Play 0.0135” ± 0.0111” (0.3450 ± 0.2825 mm)
Counter
Balance
End Play 0.005” (0.127 mm)
Cylinder
H
d
Surface warpage limit 0.00394” (0.1 mm)
y
Head
Standard height 3.478” (88.35 mm)
Valve Seat Contacting width In
Std 0.0472” + 0.00787” -- 0.0039”
(1.20 + 0.20 -- 0.10 mm)
Ex
Std 0.0591” + 0.00787” -- 0.0039”
(1.50 + 0.20 -- 0.10 mm)
Seat Angle Std 44.75 ± 0.25°
Valve
G
i
d
Inner diameter 0.2374” ± 0.00059” (6.030 ± 0.015 mm)
Guide
Protrusion above head 0.5610” ± 0.00394” (14.25 ± 0.10 mm)
Valve Margin thick- In
Std 0.1394” ± 0.0065” (3.541 ± 0.165 mm)
g
ness
Ex
Std 0.1373” ± 0.0065”(3.488 ± 0.165 mm)
Stem diameter In 0.2356” ± 0.00039” (5.985 ± 0.01 mm)
Ex 0.2346” ± 0.00039” (5.96 ± 0.01 mm)
Stem oil clear- Std
In 0.00177” ± 0.00098” (0.045 ± 0.025 mm)
ance
Ex 0.00334” ± 0.00039” (0.085 ± 0.010 mm)
Overall length
In 4.51” ± 0.01476” (114.5550 ± 0.375 mm)
g
Ex 4.5453” ± .01496” (115.45 ± 0.38 mm)
Valve
Spring
Overall length
Free
Length
1.8267” (46.40 mm)
p
g
Installed
Height
1.47” (37.34 mm)
