FUEL SYSTEM / CARBURETION
4.4
FUEL FLOW
Fuel Tanks
Fuel Valve
Engine
Filter
Fuel Pump
Carburetor
Fuel Tank Vent
Carburetor Vent
Fitting Screens
L
L Located Above Oil Tank
FUEL FLOW
Fuel Flow Diagram
ValvetoPumpLine
Impulse Line
Pump to Carburetor Line
Fuel Filter
Carburetor
Vent Line
Front Fuel Tank
Fuel Pump
FRONT
TANK
OFF
REAR
TANK
Rear Fuel Tank
3WayValve
NOTE: See Chapter 2 “FUEL TANKS AND FUEL VALVE”
for more information on proper usage.
