FINAL DRIVE
7.22
CAUTION:
Use an arbor press only on the outer race, as
bearing damage may occur.
4. Install snap ring into groove.
REAR DRIVE SHAFT
REMOV
AL
1. Remove rear hub and bearing carrier. (See
Pages 7.19).
2. Tip hub outward and remove shaft from hub.
3. Pull sharply outward to remove shaft from
transmission. Install a new lock ring upon
assembly.
Pull outward sharply to re-
move from transmission
Lock ring
