CLUTCH
6.6
PVT COVER
REMOVAL/INST
ALL
1. Refer to the “PLASTIC FOOT WELL REMOVAL /
INSTALLATION“ in Chapter 5 for removal
procedure to gain access to the PVT cover.
2. The PVT cover should now be accessible. If
necessary remove the rear right cab assembly.
Remove the three plastic inserts that secure the
rear cab to the frame. Remove the seat latch bolt
also. (See “PLASTIC INSERT REMOVAL /
INSTALLATION” in Chapter 5 for help).
Remove Plastic Inserts
3. The PVT cover is now accessible. Remove the
PVT cover bolts (9) and the PVT cover intake
clamp.
Remove 9 Screws
To Next Page
