Polaris RANGER CREW 900 EPS 2014 - Camshaft Timing - Quick Reference

3.82
9924880 Rev 2- 1/10/2014 - 2013 / 2014 RANGER XP 900 - 2014 RANGER XP 900 / CREW 900 Service Manual
© Copyright Polaris Sales Inc.
CAMSHAFT TIMING - QUICK REFERENCE
q
Intake Cam
r
Align Exhaust Marks With Surface
w
Exhaust Cam
t
CPS Mounting Hole
e
Align Intake Marks With Surface
y
Align Flywheel Mark in Mounting Hole
ENGINE
