7.4
9924880 Rev 2- 1/10/2014 - 2013 / 2014 RANGER XP 900 - 2014 RANGER XP 900 / CREW 900 Service Manual
© Copyright Polaris Sales Inc.
BEARING REPLACEMENT
Bearing Removal
1. Remove outer snap ring.
2. From back side of the bearing carrier, tap on the
outer bearing race with a drift punch in the reliefs as
shown.
3. Drive bearing out evenly by tapping on outer race
only. Once bearing is at bottom of casting, support
casting on outer edges so bearing can be removed.
4. Inspect bearing carrier housing for scratches, wear
or damage. Replace front bearing carrier if damaged.
Bearing Installation
5. Thoroughly clean the front bearing carrier housing
and the outer race on the new bearing. Be sure that
all oil residue has been removed from each surface.
6. Support the bottom of the bearing carrier housing.
CAUTION
Use an arbor and press only on the outer race,
otherwise bearing damage may occur.
7. Apply Loctite
®
603 retaining compound to the outer
circumference of the new bearing race and carefully
press the new bearing into the bearing carrier
housing.
NOTE
Use care to not allow any of the Loctite
®
compound to
get in the bearing.
8. Wipe the housing clean of any excess compound
and install the snap ring.
FINAL DRIVE
