5
9924880 Rev 2- 1/10/2014 - 2013 / 2014 RANGER XP 900 - 2014 RANGER XP 900 / CREW 900 Service Manual
© Copyright Polaris Sales Inc.
5.45
REAR LOWER A-ARM INSTALLATION
WARNING
The locking agent on the existing bolts was destroyed
during removal. DO NOT reuse old hardware. Serious
injury or death could result if fasteners come loose
during operation.
1. Install the lower A-arm on the frame. Torque new
fasteners to specification.
TORQUE
Lower A-Arm to Frame:40 ft-lbs (54 Nm)
2. Attach the lower A-arm to the bearing carrier. Torque
new fastener to specification.
TORQUE
Lower A-Arm to Bearing Carrier:40 ft-lbs (54 Nm)
3. Attach the lower portion of the rear shock to the
lower A-arm. Torque new fastener to specification.
TORQUE
Shock Mounting Bolts:40 ft-lbs (54 Nm)
4. Attach the lower stabilizer bar link to the lower A-
arm. Torque new fastener to specification.
TORQUE
Stabilizer Link to Lower A-Arm:17 ft-lbs (23 Nm)
5. Attach the stabilizer bar to the frame. Torque
fasteners to specification.
TORQUE
Stabilizer Bar to Frame:17 ft-lbs (23 Nm)
6. Install wheel and torque wheel nuts to specification
(see Chapter 2).
WARNING
Upon A-arm installation completion, test vehicle at low
speeds before putting into service.
BODY / STEERING / SUSPENSION
