Polaris RANGER CREW 900 EPS 2014 - Page 208

5
9924880 Rev 2- 1/10/2014 - 2013 / 2014 RANGER XP 900 - 2014 RANGER XP 900 / CREW 900 Service Manual
© Copyright Polaris Sales Inc.
5.9
REF.
PART DESCRIPTION NOTE
1 DECAL, DOOR, TOP
2
DECAL, DOOR, BOTTOM
3
ASM., DOOR, BLACK
4
ASM., LATCH DOOR
5
BRACKET, HINGE, SUPPORT, MATTE BLACK
6
ROD, DOOR, LATCH
7
GROMMET, SEATFILLER, TRUNK
8 BUMPER, RUBBER
9 PANEL, DOOR
10
COVER, LATCH, INNER
11
ACTUATOR, SPRING
12
SCREW
13
SCREW
14
PANEL, DOOR, OUTER
15 RIVET
16
HINGE, LOWER
17 HINGE, UPPER
18
ASM., STRIKER
19 BRACKET, HINGE
20
WASHER, NYLON
21 SCREW Torque: 14 ft-lbs. (19 Nm)
(Torque when Fastening Ref. 16 to the vehicle)
22 SCREW Torque: 8 ft-lbs. (10 Nm)
BODY / STEERING / SUSPENSION
