6.10
9924880 Rev 2- 1/10/2014 - 2013 / 2014 RANGER XP 900 - 2014 RANGER XP 900 / CREW 900 Service Manual
© Copyright Polaris Sales Inc.
5. Remove the drive clutch retaining bolt and remove
the drive clutch using Drive Clutch Puller 2872085.
Drive Clutch Puller 2872085
NOTE
Be sure to use the correct Drive Clutch Puller (PN
2872085) to prevent damage to crankshaft.
6. Remove the fuel line (D) and wiring harness (E) from
the inner clutch cover restraints.
7. Using a 10mm socket, remove the (7) bolts that
retain the inner clutch cover to the engine and
transmission.
8. Remove the inner clutch cover from the vehicle.
CLUTCHING
