8.8
9924880 Rev 2- 1/10/2014 - 2013 / 2014 RANGER XP 900 - 2014 RANGER XP 900 / CREW 900 Service Manual
© Copyright Polaris Sales Inc.
15. Use an overhead or portable hoist to support the
transmission by securing a strap (T) through the rear
mount.
NOTE
Place a spacer or support between the vehicle frame
and engine to hold the engine up in position while
removing the transmission to engine mounting bolts.
16. Using a 15mm socket, remove the (4) bolts from the
left side (U) and right side (V), securing the
transmission to the engine.
17. Remove the rear transmission mount bolt (W).
TRANSMISSION
