9.4
9924880 Rev 2- 1/10/2014 - 2013 / 2014 RANGER XP 900 - 2014 RANGER XP 900 / CREW 900 Service Manual
© Copyright Polaris Sales Inc.
TORQUE SPECIFICATIONS
ITEM
FT-LBS
(IN-LBS)
NM
Brake Disc to Hub Bolts (Front)
18 24
Brake Disc to Hub Bolts (Rear)
28 38
Brake Line Banjo Bolts (All)
15 20
Brake Line Flare Fittings
12-15 16-20
Brake Switch 15 20
Caliper Bleed Screws (47)
5
Caliper Mounting Bolts (Front)
30 41
Caliper Mounting Bolts (Rear)
48 65
Front Brake Scraper Screws
7 10
Master Cylinder Mounting Bolts
23 31
Pedal Mount Bracket Nuts 18 24
SPECIAL TOOLS
PART NUMBER TOOL DESCRIPTION
2870975
Mity Vac™ Pressure Test Tool
Bosch Automotive Service Solutions:
1-800-328-6657 or http://polaris.service-solutions.com/
BRAKES
