Polaroid ModelSmart 250S User Manual

11
Change Filament
Main Menu Continue
Install the cartridge and firmly feed the filament
through the tube until it stops, whilst maintaining
pressure on the filament, press continue to start
the extrusion.
You then need to install the cartridge onto the side of the printer. Firstly, remove the lament
cartridge from the outer packaging and take out the red plug from the side of the cartridge casing.
Slide the cartridge onto the lament holder on the side of the printer and gently push until you hear
it click into place.
Next, gently pull out sufcient lament from the cartridge (5cm to 15cm). Cut off the rst 5cm of
the lament and discard (this is to ensure that any previously exposed lament does not enter the
printer as it may have some dirt on it). Then push the lament coming from the cartridge through
the lament tube (item J). Feed the lament through the lament tube into the corresponding
tting on the side of the printer.
You will then be asked if a lament cartridge
is already installed. Initially this will be ‘No’
as this is the rst time a lament cartridge has
been loaded; but when changing a cartridge in
future you will select ‘Yes’. Selecting ‘Yes’ will
uninstall the existing lament before allowing
you to load a new lament.
Continue feeding the lament into the printer until it you feel it stops. Approximately 30cm of
lament will be required.
5

Polaroid ModelSmart 250S Specifications

General

Print technology	-
Printing material	Polylactic acid (PLA), Wood fiber
Maximum travel speed	100 mm/sec
Layer thickness (max)	350 mm
Layer thickness (min)	50 mm
Maximum build size (WxDxH)	250 x 150 x 150 mm
Filament thickness supported	1.75 mm
Control type	Wireless
Viewing window	Yes
Print resolution	- DPI
3D scanner	No
Compatible memory cards	SD
AC adapter output voltage	24 V
Cables included	AC, USB

Weight and Dimensions

Depth	150 mm
Width	250 mm
