Polaroid ModelSmart 250S User Manual

12
Whilst maintaining gentle pressure (to ensure that the lament has been fed all the way through
correctly), please press the on-screen ‘Continue’ button which will start the extrusion process.
You should then feel the lament being pulled through the printer and see lament being extruded
through the nozzle. When this is complete the ‘Continue’ button will become active and you can
complete the process.
If no lament is extruded, ensure that the lament has been pushed all the way through and whilst
maintaining gentle pressure please push the ‘Repeat Process’ button.
Once the lament has been installed, push the end of the lament tube onto the top of the
cartridge and into the tting on the side of the printer, ensuring that no lament is left exposed.
If removing a part-used lament,
please ensure that you do not push
the end of the lament back into the
cartridge casing as this means that
you will then not be able to attach
this cartridge to the printer again for
printing.
Part-used cartridges should be
stored in a cool and dry environment
whilst not in use.
Change Filament
Main Menu
Repeat Process
Continue
If no filament is extruded after 30 sec, please press
‘Repeat process’.
Change Filament
End
Change of filament is complete.

Polaroid ModelSmart 250S Specifications

General

Print technology	-
Printing material	Polylactic acid (PLA), Wood fiber
Maximum travel speed	100 mm/sec
Layer thickness (max)	350 mm
Layer thickness (min)	50 mm
Maximum build size (WxDxH)	250 x 150 x 150 mm
Filament thickness supported	1.75 mm
Control type	Wireless
Viewing window	Yes
Print resolution	- DPI
3D scanner	No
Compatible memory cards	SD
AC adapter output voltage	24 V
Cables included	AC, USB

Weight and Dimensions

Depth	150 mm
Width	250 mm
