Poly G7500

Poly G7500 | Room Preparation Guide 3.3.0
Poly, Inc. 16
RealPresence Group Series Serial Cable
Length
Part Number
RoHS Compliant
3 m (9.8 ft)
2457-63542-001
Yes
Straight-Through Cable
Use this cable to connect a G7500 system to a serial device. It has a DB-9 connector on each end. The
maximum approved length is 30 m (100 ft).
Recommendation for Use
Poly doesn’t recommend using this straight-through serial cable for RS-232 communication from a
computer, Creston system, or AMX device. For RS-232 communication, use a cross-over cable with pin 2
wired to pin 3, pin 3 wired to pin 2, and pin 5 wired to pin 5. The other pins aren’t used.
Straight-Through Cable
Length
Part Number
RoHS Compliant
7.6 m (25 ft)
2457-09172-001
Yes
