Chapter 2 -
2-44
Web User Interface (UI)
playback address that includes the public network IP address or DNS name.
For more details about external IP settings, please refer to
IP Address Settings.
Permission of an archive are not stored on the archive when sending it as email link.
This is the reason that the email link option is available only for the administrator who
can make the decision if to use this functionality..
Deleting Archives
To delete a file on the video table, after selecting this archive’s corresponding
check box, click the “Delete” button. The user can select one video or multiple
videos for deletion. The user can also select all videos for deletion by
checking the check box in the header.
The first check box under the “New” button on the Archives page is Select All. All of
the archives will be checked if this check box is selected.
Go to Archive Pages
The current page number and total number of pages are shown in the top
right corner of the archives table.
The buttons to the right of the page numbers are used for page turning. The
button on the far left and the one on the far right
are used to return
to the first page or jump to the last page, respectively. The two middle
buttons
go to the previous page and the next page, respectively. To
jump to any page, enter a page number into the blank field on the right and
then click the
button.
H.323 Connection Status Display
The recording status of the endpoint currently connected to the RSS 2000 can
be displayed in real time on the bottom of the web page, as shown below.
Recording control and status display can be done for the connections that
show the H.323 connection status as connected.
Figure 2-49 H.323 Connection Status Display Area
