Polycom SoundPoint IP 550 Quick Reference Guide

12
Lets you place a
call on hold so that
another user can
answer it!
Call Park
To Park a Call:
Place the call on holdSTEP 1
Press the ‘New Call’ softkey.
STEP 2
Press
*68
STEP 3
Enter the extension where you want to park the call or
press # to park it at your own extension, then hang up
STEP 4
To pick up a parked call, press
*88
STEP 5
Enter the extension where the call is parked or press # to
retrieve it from your own extension
STEP 6
To Forward Your Calls to Another Number
†
:
Press the ‘Forward’ softkey
STEP 1
Select the line/extension from which you would like calls
forwarded and press the
‘Select’ softkey
STEP 2
Enter the number to which you would like calls forwarded
and press the ‘Enable’ softkey
STEP 3
To disable call forwarding repeat steps 1 and 2 and press the
‘Disable’ softkey
† Call Forwarding can also be enabled from your Web Portal explained on page XX
STEP 4

Polycom SoundPoint IP 550 Specifications

General

Full duplex	Yes
Camera included	No
Frequency range	150 - 7000 Hz
Base station keys	26 + 4
Channels quantity	2 channels
Dimensions (WxDxH)	265 x 150 x 190 mm
Networking features	DHCP/Static IP
Ethernet LAN (RJ-45) ports	2
Supported network protocols	FTP, TFTP, HTTP, HTTPS
Supported data transfer rates	10/100 Mbit/s
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	20 - 85 %
Power requirements	48V DC
Volume control	Digital
Voice codecs	G.722
Backlight color	-
Display resolution	320 x 160 pixels
Safety	UL/C-UL; CE Mark-1; EN 60950-1; IEC 60950-1; AS/NZS 60950
Certification	- FCC Part 15 (CFR 47) Class B - ICES-003 Class B - EN55022 Class B - CISPR22 Class B - AS/NZS CISPR 22 Class B - VCCI Class B - EN55024 - EN61000-3-2; EN61000-3-3 - ROHS - Anatel - GOST - C-tick - CCC
Compliance industry standards	IEEE 802.3af; IEEE 802.1p;IEEE 1329; RFC 1889

Weight and Dimensions

Weight	2045 g
