Customizing SoundStructure Designs
5 - 27
The signal processing associated with the low delay option is shown in the fol-
lowing figure for both the ungated sound reinforcement path and automixed
sound reinforcement paths.
Delay Compensation
The delay compensation control adds a fixed delay to the line input and
bypass signal processing paths to keep the different version of the input pro-
cessing time aligned through the input processing.
Microphone inputs have approximately 16 msec of latency due to the AEC and
noise cancellation processing. By selecting delay compensation, 16 msec of
delay is added to the line input and bypass ungated signal types.
