PORTABLE ELECTRIC VOLTstack 5k - Spec Sheet

40
DC CHARGING
Input: Up to two SUNstack
TM
solar kits supplied by Portable Electric
STORAGE
5.6 kWh
Battery Type: Lithium-Ion
OUTLETS
2 x 120VAC 20 Amp Receptacles (NEMA 5-20R type)
2 x 20 Amp Circuits
2 x 5 VDC USB Receptacles
RATED OUTPUT
4.8 kW Pure Sine Wave Inverter
(Surge rating: 5.8 kW 3 sec, 7 kW peak)
AC OUTPUT
Single Phase 120V @ 40A Continuous
(20A per circuit)
AC CHARGING
2 x 120VAC 15 Amp receptacle (NEMA 5-15P type)
Recharge time @ 30 Amps (120V) is 2.5 hrs, @ 15A (120V) is 5 hrs
OPERATING CONDITIONS
Operating temperature (discharging): -20°C up to 50°C
Operating temperature (charging): 0°C up to 50°C
CARBON OFFSET EQUIVALENT
O sets 15 kg of CO
2
e for 8 hours operation
VOLTstack®5k Unit
BOX MECHANICAL SPECS
Weight: 330 lbs / 150 kg
Four wheel (two stationary, two swivel) polymer casters
Dimensions (L x W x H):
Box - 31’’ x 20’’ x 29’’ / 79cm x 51cm x 74cm
Shipping - 33’’ x 23’’ x 31’’ / 84cm x 58cm x 79cm
SAFETY
Non-Combustible Aluminum Enclosure
Conforms to UL STD 1640
Certifi ed to CSA 22.2 # 14
Recommended storage temperature: 10°C - 30°C
SPECIFICATIONS
Version 1.0 September 2019
