G2000/G3000/G6000 Industrial User’s Manual Chapter 2: Setup and Use
6
Figure 3
1. Printhead Module 2. Printhead Bracket 3. Printhead
4. Transmissive Sensor
5. Reflective Sensor
6. TPH Release Lever
7. Media Guide 8. Ribbon Loading Knob 9. Ribbon Supply Spindle
10. Media Compartment
11. Guide Wheel
12. Platen Roller
2
1
3
4
12
6
7
8
9
10
11
5
