G2000/G3000/G6000 Industrial User’s Manual Chapter 1: Introduction
2
Chapter 1: Introduction
Printer Specifications
Model G2000 G3000 G6000
Printing method Direct Thermal & Thermal Transfer
Printing resolution 203 dpi (8 dots/mm) 300 dpi (11.8 dots/mm) 600 dpi (23.6 dots/mm)
Max printing speed 6ips (76.2 mm/s) 6ips (76.2 mm/s) 3ips (76.2 mm/s)
Max printing width 4.25″ (108 mm) 4.17″ (106 mm) 4.16″ (105.6 mm)
Max printing length 157″ (4000 mm) 40″ (1016 mm)
8 MB Flash ROM, 16 MB SDRAM
Media Roll-feed, die-cut, continuous, fan-fold, tags, tickets in plain paper or thermal paper
Width: 4.3″（110 mm）max., 0.98″（25 mm）min.
Supply roll: OD 6″ (152 mm) max., ID 1″ (25.4 mm) min.
Thickness 0.003″~ 0.008″ (0.08 ~ 0.20 mm), including liner
Ribbon Wax, Wax/Resin, Resin
Ribbon roll: OD 2.75″ (70 mm) max., ID 1″ (25.4 mm) core
Max width: 4.3″ (110 mm); Max length: 984.25’ (300 m), Ink side: Out
Fonts Five built-in ASCII fonts, downloadable truetype fonts.
Bar Code types
1D Barcode : Code 39, Code 93, Code 128/subset A,B,C, Codabar, Interleave 2 of 5, UPC A/E 2
and 5 add-on, EAN-13/8/128, UCC-128, etc.
2D Barcode : MaxiCode, PDF417, Data Matrix, QR, etc.
Reflective (Adjustable) / Transmissive
RS-232 Serial, USB2.0, 10/100M Ethernet, and USB HOST
LCD Display Four lines dot matrix LCD
Power rating* 24 VDC, 4.0 A
Weight 7.72lbs (3.5 kgs)
Dimensions W 10.07″ x D 12.95″ x H 7.8″ (W 256 x D 329 x H 200 mm)
Operation environment
Temperature: 32° F ~ +104° F (0° C ~ 40° C)
Relative humidity: 5% - 85% non condensing
Storage environment
Temperature: -40° F ~ +140° F (-40° C ~ 60° C)
Relative humidity: 5% - 85% non condensing
Optional items External Rewinder, External Media Stand, Rotary Cutter, Centronics Parallel
Adapter
*
Power for the G6000 Industrial barcode label printer is provided via an external power adaptor.
**Some optional items may require minimum quantities and/or factory installation. Please contact a Postek sales representative for complete
details.
