Chapter 3: Setup and Use Q8 Series User’s Manual
6
Figure 3
1.Ribbon Take-up 4.Printhead Module Plate 7.Media Compartment
2.Printhead Bracket 5.Ribbon Release Knobs
3.Handle 6.Ribbon Supply
6
2
3
4
5
7
1
