Q8 Series User’s Manual Chapter 1: Introduction
2
Chapter 1: Introduction
Technical Specifications
Printer Specifications
Mode Q8/200 Q8/300
Printing method Direct Thermal & Thermal Transfer
Printing resolution 203 dpi (8 dots/mm) 300 dpi (11.8 dots/mm)
Max printing speed 4 ips (101.6 mm/s) 3 ips (76.2 mm/s)
Max printing width 4.25″ (108 mm) 4.17″ (106 mm)
Max printing length 157″ (3987.8 mm) 79” (2006.6 mm)
Memory 2 MB FLASH ROM, 8 MB SDRAM
Media
Roll-feed, die-cut, continuous, tags, tickets in plain paper or thermal paper
Width：4.33″ (110 mm) max., .98″ (25 mm) min.
Supply roll: OD 5″ (127 mm) max., ID 1″ (25.4 mm) min.
Thickness: 0.003″～0.006″ (0.08～0.15 mm), including liner
Ribbon
Wax, Wax/Resin, Resin
Ribbon roll: OD 3″ (76.2 mm) max., ID 1″ (25.4 mm) core
Max width: 4.33” (110 mm); Max length: 360’ (100 M)
Fonts Five built-in ASCII fonts; Optional multiple language fonts
Bar Code Types
1D Barcode : Code 39, Code 93, Code 128/subset A,B,C, Codabar, Interleave 2 of 5, UPC A/E
2 and 5 add-on, EAN-13/8/128, UCC-128.
2D Barcode : MaxiCode, PDF417, Data Matrix.
Media sensor Reflective
Interfaces RS-232 Serial, USB
Power rating 24 VDC Power adapter
Weight 5.29lbs (2.4 kgs)
Dimensions W 8.27” x D 10.04” x H 5.9” (W 210 x D 255 x H 150 mm)
Operation
environment
Temperature: 32° F ~ +104° F (0° C ~ 40° C)
Relative humidity: 5% - 85% non condensing
Storage
environment
Temperature: -40° F ~ +140° F (-40° C ~ 60° C)
Relative humidity: 5% - 85% non condensing
Optional items Guillotine Cutter, Peeler Kit, External Rewinder
