Description of the appliance
1
Sensor for air humidity measurements
2
Sensor for light measurements
3
Sensor for sound measurements
4
Button LIGHT
5
Button REL
6
Fold-out stand
7
Socket VΩ , positive
8
Socket COM, negative
9
Socket mA °C
0
Socket 2A
q
Function switch
w
Button Hz/DUTY
e
Button RANGE
r
Button FUNC.
t
Button HOLD
z
Display
u
Battery compartment cover
Measuring leads with measurement prods
Temperature sensor (on the red adaptor)
Measuring leads with measurement plugs
Battery compartment (on the rear)
