- 34 -
Direct current voltage measurement
Overload protection: Measurement range 40 mA - 400 mA:
Fusing 500 mA/600 V Measurement range 2 A: Fusing 2 A/600 V
Alternating current voltage measurement
Overload protection: Measurement range 40 mA - 400 mA:
Fusing 500 mA/600 V
Measurement range 2 A Fusing 2 A/600 V
Resistance measurement
Off-load voltage: 0,25 V Overload protection: 250 V /
~
RMS
Measurement Range Resolution Precision
400 Ω 0,1 Ω +/- (1,2% f.m.r. +/- 2 points)
4 kΩ 1 Ω
40 kΩ 10 Ω
400 kΩ 100 Ω
4 MΩ 1 kΩ
40 MΩ 10 kΩ +/- (2,0% f.m.r. +/- 5 points)
Measurement Range Resolution Precision
40 mA 10 µA +/- (1,5% f.m.r. +/- 5 points)
400 mA 100 µA +/- (1,5% f.m.r. +/- 5 points)
2 A 10 mA +/- (2,0% f.m.r. +/- 10 points)
Measurement Range Resolution Precision
40 mA 10 µA +/- (1,2% f.m.r. +/- 3 points)
400 mA 100 µA +/- (1,2% f.m.r. +/- 3 points)
2 A 10 mA +/- (2,0% f.m.r. +/- 10 points)
