- 21 -
Resistance measurement
Caution!
Before attachment of the measurement leads, the object being tested must
be de-energised, so as not to damage the device or the object being tested. In
cases of doubt, the freedom from energy must be proved by measurement.
• Place the function switch
q
at the position .
• If necessary, press the button
FUNC.
r
until the indicator MΩ appears
in the display
z
.
• Insert the measuring leads into the input sockets
VΩ
7
and COM
8
.
• Connect the measurement prods with the object being tested.
The measured value is shown in the display
z
in Megaohm (MΩ),
Kiloohm (kΩ) or Ohm (Ω).
Adjusting the measurement conclusion
• Press the button RANGE
e
once to switch from the automatic to the
manual measurement conclusion.
The indicator AUTO extinguishes.
