- 29 -
Measuring conductivity
Caution!
For the measurement of current, the object being tested must be switched in
series.
• For the measurement of currents up to 400 mA, place the function
switch
q
at the position .
• Insert the measuring leads into the input sockets
mA °C
9
and COM
8
.
• For the measurement of currents up to 2 A, place the function switch
q
at the position .
• Insert the measuring leads into the input sockets
2A
0
and COM
8
.
The indicator for direct voltage measurement appears.
• Press the button
FUNC.
r
to switch between either direct current or
alternating current measurement .
• Connect the measurement prods with the object being tested.
The measured value is shown in the display
z
, subject to current strength,
in milliampere (mA) or ampere (A).
