Installation
23
Powerware
®
5125 Two-in-One (2400–3000 VA) User’s Guide : www.powerware.com
9. Align each EBM bracket with the adjacent corner screw holes
and secure with the supplied screws.
EBM Bracket
EBM
UPS
EBM Bracket
Figure 12. Installing the EBM Brackets (Top View with Pedestals)
10. If installing additional EBMs, repeat Step 9 for each cabinet.
Continue to the following section, “Installing the UPS.”
