Initiating the Self-Test
NOTE The batteries must be fully charged and the UPS must not be in Battery mode
to perform the self-test.
Press and hold the button for three seconds to initiate the self-test.
During the test, individual indicators illuminate as various parts of the
UPS are checked. If the alarm beeps or a UPS alarm indicator stays on,
see Table 8 on page 52.
Operating Modes
Powerware 5125’s front panel indicates the UPS status through the UPS
indicators. Figure 18 shows the UPS front panel indicators and controls.
On Button
Off Button
Test/Alarm Reset Button
Normal Mode Indicator (Solid Green)
Standby Mode Indicator (Flashing Green)
Bypass Mode Indicator (Solid Red)
Red
Flashing
Unlit
Green
Indicator Legend
Load Level IndicatorsBattery Mode Indicator
Battery Service Indicator
Figure 18. UPS Front Panel
