Powerware 5125 - Page 33

Installation
27
Powerware
®
5125 Two-in-One (2400–3000 VA) User’s Guide : www.powerware.com
REPO Port
IEC 320-C19 Receptacle
Battery Connector
16A, IEC 320-C20
Input Connector
Communication Port IEC 320-C13 Receptacles
X-Slot
Circuit Breakers
Figure 17. 3000 VA, 200–240V (PW5125 3000g RM) Rear Panel
