Powerware 9315 (500 kVA--750 kVA) T1 and T3 Installation Addendum
164201244--001 REV. A 011500
FRONT
INVERTER
BAFFLE
BLOWER ASSEMBLY
B12---B15
SIDE
INVERTER
BAFFLE
F i g u r e 2 --- 4 . O u t p u t / I n v e r t e r B l o w e r A s s e m b l y B 1 2 --- B 1 5 I n v e r t e r B a f f l e s
