Powerware 9315 - Bypass Mode

2-- 7
Powerware 9315 (500 kVA--750 kVA) T1 and T3 Installation Addendum
164201244--001 REV. A 011500
FRONT
TRANSFORMER
BAFFLE
TRANSFORMER
MOUNTING B OLTS
(8 PLACES)
H1
H2 H3
H11
H21
H31
TRANSFORMER TERMINALS
X1 X01 X2
X02 X3 X03
TRANSFORMER TERMINALS
Figure 2 ---5. Transformer T1 Wiring
